HUAWEI H901HTED 50G PON HTED

Product description: HUAWEI H901HTED 8-port Enhanced Symmetric 50G-PON&XGS-PON&GPON Triple-mode Combo OLT Interface Board
INQUIRY

We can provide Huawei's latest 50G PON products, including symmetric versions of 50G PON, and offer third-party 50G PON compatible solutions. If you have testing requirements for ONU chips or third-party ONU products, please send your requirements to my email: jason.liu@dewuit.com

The board is an 8-port enhanced symmetric 50G-PON & XGS-PON & GPON triple-mode combo OLT interface board. It works with ONUs to provide symmetric 50G-PON & XG(S)-PON & GPON service access.

Functions and Features	Description
Port quantity	8
Port rate mode	Symmetric
Port rate	Symmetric 50G-PON upstream/downstream channel: 49.7664/49.7664 Gbit/s Asymmetric 50G PON upstream/downstream channel: 24.883/49.76642 Gbit/s XGS-PON upstream/downstream channel:9.953/9.953 Gbit/s XG-PON upstream/downstream channel:2.488/9.953 Gbit/s GPON upstream/downstream channel:1.244/2.488 Gbit/s
Supported ONU types	Symmetric 50G-PON: 50G/50G (downstream rate/upstream rate) Asymmetric 50G-PON: 50G/25G (downstream rate/upstream rate) XGS-PON: 10G/10G (downstream rate/upstream rate) XG-PON: 10G/2.5G (downstream rate/upstream rate) GPON: 2.5G/1.25G (downstream rate/upstream rate)
